Continuous Stirred-Tank Reactor LE-CSR101

Name: Continuous Stirred-Tank Reactor LE-CSR101
Brand: Labexpo
SKU: LE-CSR101
Rating: 4.4 (641 reviews)

Continuous Stirred-Tank Reactor LE-CSR101 is designed with a 250 ml capacity, suitable for precise and controlled batch. It offers a variable stirring speed range from 0 to 1500 rpm to enable control over mixing intensity. Equipped with a control panel for accurate and stable thermal regulation. Built with needle valve to allow fine control of gas or liquid flow during operation. Our Reactor is an ideal choice for laboratory-scale reaction and mixing processes.

Specifications

Volume	250 ml
Maximum Working Pressure	Standard 100 bar; Max Pressure Up to 350 bar
Operating Temperature	Standard 350°C; Up to 500°C
Stirring Speed	0 to 1500 rpm
Motor Power	150 W
Heating Power	1 KW
Heating Method	Electric Heater with Insulation (PID Control)
Cooling	Internal Spiral Coils
Shaft Sealing	Magnetic Coupling Drive (Belt Drive)
Material	SS304 or SS316

Features

Temperature range 5 C to 35 C with digital display monitoring
Maximum working pressure standard 100 bar max pressure up to 350 bar
Shaft sealing magnetic coupling drive belt drive
Operating temperature standard 350 C up to 500 C
Heating method electric heater with insulation PID control

Applications

Function	Implementation
Lab-Scale Reaction Processes	1 kW heating power enables precise temperature control
Precise Mixing Operations	Variable stirring speed range from 0 to 1500 rpm ensures optimal mixing
Thermal Regulation in Labs	±1°C accuracy supports repeatable analytical results
Small-Scale Chemical Synthesis	Standard 100 bar working pressure accommodates various chemical reactions
Laboratory-Scale Mixing Applications	Internal spiral coils facilitate efficient cooling

Catalog

Continuous Stirred-Tank Reactor LE-CSR101 Catalog
