Dry Bath LE-DB302 offers a wide temperature setting range from -10℃ to 100℃. Its lightweight, portable design supports both 12V and 24V power sources for on-the-go operation. Equipped with fast heating/cooling and microprocessor accuracy, it ensures consistent, high-performance results. Our Dry Bath is ideal for DNA amplification, sample preservation, and electrophoresis preparation, which performs reliably in compact spaces.
Specifications
| Temp. setting range | -10℃ to 100℃ |
| Temp. control range | RT - 15℃ to 100℃ |
| Timing range | 1 sec to 5999 sec / ∞ |
| Temp. accuracy | ≤ ±0.3℃ |
| Display accuracy | 0.1℃ |
| Heating time | ≤ 20 min (from 25℃ to 100℃) |
| Cooling time 1 | ≤ 20 min (from 100℃ to 25℃) |
| Cooling time 2 | ≤ 25 min (from RT to RT - 15℃) |
| AUTO-4℃ | Yes* |
| Multi points running | Yes (Max 5 points) |
| Multi cycle | Yes (Max. 99 times) |
| Auto heating | Yes |
| Power Consumption | 60 Watt |
| Power Supply | DC 12V / 5A |
| Dimensions | 145 × 113 × 140 mm |
| Weight | 1.0 kg |
Features
Applications
Function Implementation Research labs ±0.3℃ temperature accuracy supports precise sample analysis Clinical settings 60 Watt power consumption enables efficient continuous operation Industrial testing 20 min heating time from 25℃ to 100℃ facilitates rapid thermal cycling Quality control -10℃ to 100℃ temperature setting range allows for versatile testing conditions Institutional facilities 145 × 113 × 140 mm dimensions enable compact and space-efficient installation
Optional Accessories
Block – 2.0ml × 15
Block – 1.5ml × 15
Block – 0.5ml × 24
Block – 0.2ml × 32
Catalog
1: What makes this dry bath unique compared to standard models?
The LE-DB302 provides both heating and cooling functions, operating within a range of -10°C to 100°C for versatile laboratory use.
2: Can this equipment be used outside traditional lab setups?
These dual power options allow portable, on-the-go operation, making it suitable for fieldwork and mobile labs.
3: How does the system ensure precise control during experiments?
They achieve this through microprocessor-based accuracy with 0.1°C display resolution.
4: What kind of advanced features are built into this model?
Our Dry Bath includes multi-point running, multi-cycle programming, automatic cooling, and quick heating/cooling modes.
5: How efficient is it in switching between heating and cooling?
It can heat from 25°C to 100°C in 20 minutes and cool from 100°C to 25°C in ?20 minutes, ensuring rapid transitions.
6: What is a Dry Bath Incubator used for?
A Dry Bath Incubator is used to uniformly heat samples in a laboratory setting, commonly for applications like enzyme reactions, DNA denaturation and cell culture incubation.
7: What is the purpose of the calibration screw on a Dry Bath Incubator?
The calibration screw allows for fine-tuning the temperature setting, ensuring that the actual block temperature matches the displayed temperature, which is critical for sensitive experiments.
8: What is a PID controller and how does it benefit the Dry Bath Incubator?
A PID controller continuously monitors and adjusts the temperature to maintain a stable setpoint. This ensures high-precision heating with minimal fluctuation, which is essential for consistent experimental results.
9: How does the Dry Bath Incubator ensure uniform heat distribution?
Our system uses advanced heating elements and block design that evenly distribute heat across the entire surface, ensuring all sample wells reach and maintain the same temperature.
10: How easy is it to operate the Dry Bath Incubator?
Dry Bath Incubator are designed with a user-friendly interface and intuitive controls, allowing users to quickly set temperature, time and other parameters without complex navigation.
Lab Expo Dry Bath Incubators support precision heating workflows where uniform block temperature control and repeatable setpoints are required for sample processing. The system operates with PID-regulated dry heating and interchangeable blocks to maintain stable thermal conditions across multiple samples. Dual-zone temperature control enables independent block management, while digital controls and calibration adjustment ensure controlled operation and consistent heating outcomes for routine incubation and preparation tasks.
