PCR Cabinet 56-PCC104 features a slide glass window maximizing light and visibility for the workstation. Equipped with a washable pre filter and 0.3 µm HEPA filter with a speed adjustable airflow velocity ranging from 0.3 m/s to 0.5 m/s. Manual front and side anti-UV window enclosure with an opening of 320 mm ensures user protection. Built-in preset 90 mins UV timer automatically switches off post 90 mins in preparation for next experiment. UV lamp can be switched “ON” only on closure of front window ensuring user safety.
Specifications
| UV lamp | 40 W x 1 |
| Illumination lamp | LED 12 W x 2 |
| Work surface height | 750 mm |
| Work table material | 304 stainless steel |
| Main body material | Cold rolled steel with anti-bacteria powder coating |
| Front and side window material | Anti-UV |
| Front and side window opening | 5 mm |
| Front and side window orientation | Motorized |
| Maximum window opening | 300 mm |
| Pre-filter | Washable Polyester fiber |
| HEPA filter | 0.3 µm |
| Airflow velocity ( speed adjustable ) | 0.3 m/s to 0.5 m/s |
| Illumination | ≥ 1000 Lux |
| UV lamp emission | 253.7 nm |
| UV lamp timer ( preset ) | 90 mins |
| Shelf with IV bar material | Stainless steel |
| Shelf with IV bar dimension ( W x D x H ) | 502 x 150 x 50 mm |
| Caster | Feet levelling |
| Power supply | AC 220 V ; 50 Hz / 60 Hz AC 110 V ; 60 Hz |
| Power consumption | 600 W |
| Internal dimension ( W x D x H ) | 1400 x 595 x 550 mm |
| External dimension ( W x D x H ) | 1500 x 700 x 1770 mm |
| Weight | 200 kg |
Features
Applications
Function Implementation Pre-PCR workflow control HEPA-filtered laminar airflow reducing airborne contaminants Surface decontamination High-intensity UV cycle prior to amplification steps Sample cross-contamination prevention Enclosed motorized window system maintaining clean zone Operator safety management Interlocked UV activation only when front panel is closed Genetic and molecular testing Expanded 1400 mm workspace supporting multi-sample preparation
Catalog
Lab Expo PCR Cabinets support contamination-controlled workflows where precise airflow management and surface decontamination are required for PCR and DNA amplification processes. The system operates with HEPA-filtered airflow and adjustable velocity to maintain a clean work zone. Integrated UV sterilization enables chamber decontamination between procedures, while stainless steel build supports hygienic handling. Digital airflow control and protective UV shielding ensure stable, repeatable operation during critical molecular biology work.
