Refrigerated Centrifuge 02A-RRC303 is a microprocessor controlled floor standing refrigerated centrifuge having 21000 rpm speed. It is safe, reliable, low maintenance and easy-to-use instrument equipped with LCD display and low noise flexible axle driven rotor system. With auto electric locking system fluorine free compressors and 3 tier protective steel covering, it is ideal for blood separation, protein precipitation etc. and can be used at blood station and pharmaceutical industry for variety of applications.
Specifications
| Max. Speed | 21000 rpm |
| Max. RCF | 29670 x g |
| Max. Capacity | 4 x 500 ml |
| Temp. Range | (-20) ℃ to 40 ℃ |
| Temp. Accuracy | ± 1 ℃ |
| Speed Accuracy | ± 50 rpm |
| Timer Range | 1 to 99 hr. 59 min |
| Noise | ≤ 58 dB |
| Power Supply | AC 110 to 220 V / 50 to 60 Hz / 15A |
| Dimension (H x W x D) | 690 × 715 × 430 mm |
| Packaged Dimension (H x W x D) | 875 x 785 x 560 mm |
| Net Weight | 125 kg |
| Gross Weight | 150 kg |
Features
Applications
Function Implementation Blood component separation High centrifugal force enables plasma and cellular fraction isolation Protein precipitation Refrigerated operation maintains stability during biomolecule separation RNA extraction Controlled speed and temperature support nucleic acid workflows Pharmaceutical sample processing 4 x 500 ml capacity supports batch centrifugation runs
Rotor Selection
| Rotor Name | Max. Speed (rpm) | Max. Capacity (ml) | Max. RCF (x g) |
| Swing Rotor 01 | 4000 | 4×800 (Round Cup) | 3450 |
| Swing Rotor 02 | 4000 | 4×500 ( Round Cup) | 3380 |
| Swing Rotor 03 | 4000 | 4×500 (Square Cup) | 3310 |
| Microplate Rotor 01 | 4000 | 4×4×96 Well | 2840 |
| 2×4×96 Well | 2490 | ||
| 2×3×48 Well | 2300 | ||
| Swing Rotor 04 | 4000 | 4×40×7 | 3270 |
| 4×40×5 | 2890 | ||
| 4×18×10 | 3140 | ||
| Angle Rotor 01 | 21000 | 12×1.5/2 | 30910 |
| Angle Rotor 02 | 15000 | 40×0.5 | 22920 |
| Angle Rotor 03 | 17000 | 24×1.5/2 | 26460 |
| Angle Rotor 04 | 13500 | 30×1.5/2 | 19340 |
| Angle Rotor 05 | 16000 | 16×5 | 22020 |
| Angle Rotor 06 | 14000 | 12×7 | 21380 |
| Angle Rotor 07 | 10000 | 12×15 | 11840 |
| Angle Rotor 08 | 15000 | 12×10 | 22680 |
| Angle Rotor 09 | 15000 | 8×20 | 22680 |
| Angle Rotor 10 | 14000 | 6×30 | 19060 |
| Angle Rotor 11 | 12000 | 6×50 | 16050 |
| Angle Rotor 12 | 12000 | 6×70 | 15570 |
| Angle Rotor 13 | 12000 | 4×100 | 14850 |
| Angle Rotor 14 | 12000 | 6×100 | 14850 |
| Angle Rotor 15 | 16000 | 6×10 | 21500 |
| Angle Rotor 16 | 18000 | 30×0.5 | 26660 |
| Angle Rotor 17 | 13500 | 48×1.5/2 | 17930 |
| Angle Rotor 18 | 5000 | 12×15ml | 3080 |
| Angle Rotor 19 | 5000 | 6×50ml | 2850 |
| Angle Rotor 20 | 5000 | 4×50ml | 2520 |
| Angle Rotor 21 | 5000 | 4×100ml | 2630 |
| Angle Rotor 22 | 5000 | 24×15ml | 3500 |
| Angle Rotor 23 | 5000 | 12×50ml | 3860 |
| Angle Rotor 24 | 5000 | 6×100ml | 3130 |
| Angle Rotor 25 | 4000 | 12×100ml | 2970 |
Adapter
Adapter for 800ml and 500ml bucket:
| Volume | 5ml | 7ml | 10ml | 15ml | 50ml |
| 800ml （Round Cup） | 23pcs/cup | 23 | 19 | 14 | 5 |
| 500ml （Round Cup） | 18pcs/cup | 18 | 14 | 9 | 3 |
| 500ml （Square Cup） | 20pcs/cup | 20 | 16 | 12 | 5 |
Lab Expo Refrigerated Centrifuge supports temperature-controlled separation workflows where high-speed centrifugation and active cooling are required to protect sample integrity. This cooling centrifuge operates with microprocessor-regulated speed and refrigeration to maintain defined temperatures during runs. Digital displays manage speed, time, and RCF, while electronic lid locking and protections against overspeed, overheating, and imbalance ensure controlled, repeatable centrifugation for demanding laboratory operations.
