3D Printer Fume Extractor LE-DFE301 is an air filtration system with 99.99% efficiency at 0.3 µm to capture welding smoke. It offers an energy-efficient motor paired with multi-stage filtration for optimal purification. Equipped with activated carbon filters to capture particulates and neutralize harmful gases. Integrated with a simple filter replacement mechanism to minimize downtime. Our Fume Extractor is designed for industrial and workshop use, ensuring a safer and cleaner air environment during welding operations.
Specifications
| Filtering Efficiency | 99.99% efficiency at 0. 3µm |
| Noise | Less than 60 dB |
| Cover type | Square cover |
| Colour | White |
| Air Volume | 320 m³/h |
| Port | ∅75 mm × 2 m |
| Power Supply | 220 V 50 Hz |
| Power Consumption | 200 W |
| Dimension | 420 × 240 × 450 mm |
| Weight | 18 Kg |
Features
Applications
Function Implementation Industrial workshops 200 W powers continuous air filtration 3D printing labs 320 m³/h air volume captures fumes efficiently Welding operations 99.99% efficiency at 0.3µm filters harmful particles Educational facilities Less than 60 dB noise ensures quiet operation Manufacturing floors 220 V 50 Hz power supply supports stable performance
Optional Accessories
Primary filter
Main filter
1: What is the purpose of the LE-DFE301 3D Printer Fume Extractor?
The LE-DFE301 is designed to capture and filter harmful fumes, ultrafine particles, and odours emitted during 3D printing, especially from materials like ABS, PLA, and Nylon.
2: What types of filters are used in this fume extractor?
It typically features a multi-stage filtration system including a pre-filter, HEPA filter, and activated carbon filter for efficient removal of particulate matter and VOCs (volatile organic compounds).
3: Is it compatible with all 3D printers?
Yes, LE-DFE301 is compatible with most desktop and enclosed 3D printers. It includes flexible ducting to connect to various models.
4: How efficient is the filtration system?
The HEPA filter captures up to 99.97% of particles ?0.3 microns, while the activated carbon filter absorbs chemical fumes and odours, ensuring a clean and safe working environment.
5: Does it support continuous operation?
Yes, the LE-DFE301 is designed for continuous use, provided filters are maintained and replaced as per usage.
