Biological Microscope 4-BM100 comes with 4X, 10X, 40X, and 100X (oil) objectives offering clear and high-quality images at different magnifications. It features a binocular viewing head inclined at a comfortable 45° for comfortable and flexible viewing. It has a large graphite-coated stage that offers stability and smooth movement for specimens. Our microscope has bright LED lighting with adjustable brightness for better visibility of different specimens.
Specifications
| Optical System | Finite Optical System |
| Viewing Head | Seidentopf Binocular Viewing Head Inclined at 45⁰ 360⁰Rotatable |
| Eyepiece | Wide Field Eyepiece WF10X/20mm |
| Nosepiece | Quadruple Nosepiece |
| Objective | Finite 195 Series Achromatic Objectives 4X 10X 40Xs 100Xs(oil) |
| Condenser | Abbe Condenser NA1.25 with Diaphragm, Filter |
| Focusing Unit | Coarse and Fine Adjustment Fine Division: 0.001mm Coarse Stroke: 37.7mm/Rotation Fine Stroke: 0.1mm/Rotation Moving range: 24mm |
| Stage | Double Layer Mechanical Stage: 142 × 132mm Moving Range: 75mm × 50mm |
| Illumination | External Illumination, 3W/LED |
| Packaging Dimensions | 540 × 330 × 400 mm |
| Net Weight | 7 Kg |
| Gross Weight | 9.5kg |
Features
Applications
Biological Microscope is ideal for Medical Diagnosis, Cell and Tissue Analysis, Microbiology, Genetics Research, Pharmacology and Drug Development and Environmental Science.
Optional Accessories
WF20X/12mm eyepiece
A set of finite Plan CF 4x 10x 40x 100xs (oil) objective
WF16X/15mm eyepiece
Lab Expo provides a wide range of biological microscopes designed for observing cells, tissues, and other biological specimens. They feature multiple lenses that offer magnifications ranging from 4x to 100x. These include fully coated glass optics, enclosed safety stages, and high apertures. They are designed with comfortable binocular and trinocular viewing heads. They come with advanced features such as the Infinity Corrected Optical System (ICOS) and Plan achromatic optics. Our biological microscopes are ideal for brightfield and phase contrast observation modes.
