Portable Photosynthesis Analyzer LE-PPA101 offers multi-parameter measurement for comprehensive plant physiological and environmental analysis. It measures CO₂ concentration in the range of 0 to 2000 μmol/mol with high accuracy. Equipped with a silicon photocell and correction filter for accurate PAR measurement. Integrated non-diffusion infrared CO₂ analyzer ensures precise and reliable carbon dioxide measurement. Our Portable Photosynthesis Analyzer is ideal for field studies, crop research, and plant physiology experiments.
Specifications
| CO₂ Measurement Range | 0 to 2000 μmol/mol |
| CO₂ Analysis | Non-diffusion Infrared CO₂ Analyzer |
| CO₂ Resolution | 0.1 μmol/mol |
| CO₂ Accuracy | ±3 μmol/mol |
| PAR Measurement Range | 0 to 3000 μmol/m²·s |
| PAR Accuracy | ±5% |
| Response Wavelength Range | 400 to 700 nm |
| Air Temperature Range | -20°C to 60°C |
| Air Temperature Accuracy | ±0.2°C |
| Leaf Temperature Range | 0°C to 60°C |
| Leaf Temperature Accuracy | ±0.2°C |
| Air Humidity Range | 0 to 100% RH |
| Air Humidity Accuracy | ≤ ±3% |
| Chamber Humidity Range | 0 to 100% RH |
| Chamber Humidity Accuracy | ≤ ±3% |
| Flow Rate Range | 0 to 1.0 L/min |
| Flow Rate Resolution | 0.01 L/min |
| Flow Accuracy | ±3% |
| Operating Environment | 0 to 50°C, 0 to 100% RH |
| Data Storage | 2GB SD card |
| Power Supply | DC 7.4V Lithium Battery |
| Dimension | 260 × 260 × 130 mm |
| Weight | 3.5 Kg |
Features
Adapter
Portable Photosynthesis Analyzer LE-PPA101 is widely used in biology, agronomy, horticulture, forestry, and related research fields for evaluating photosynthetic efficiency, gas exchange parameters, and environmental responses in plants.
Lab Expo Portable Photosynthesis Analyzer delivers advanced functionality with multiple measurement modes for flexible analysis. They feature a user-friendly interface with clear menu navigation and real-time data display. These analyzers include high-speed data storage with flexible options for easy export and backup. Their compact and lightweight design ensures easy portability and single-person operation. Our Portable Photosynthesis Analyzer is suitable for both indoor and outdoor use with a durable, handheld build.
