Inverted Biological Microscope 43-IBM200 is with compact & sleek design is equipped with stable & reliable ‘T’ type base, phase contrast long working distance objectives. It helps user to configure the cell more clearly thereby provides high quality images of the specimen. This user-friendly inverted microscope is used in many branches of biology.
Specifications
| Viewing head | Siedentopf type trinouclar head , inclined at 45°, interpupillary distance 52 to 75 mm, diopter adjustment |
| Eyepiece | WF10X/20, high eye-point up to 21 mm Reticule eyepiece: CROSSWF10X/20, high eye-point up to 21 mm |
| Objectives | Plan Achromatic 10X/0.25 WD=9.67 mm Plan Achromatic 20X/0.40 WD=7.97 mm Plan Achromatic 40X/0.60 WD=3.76 mm Plan achromatic positive phase contrast 20X/0.40 WD=7.97 mm |
| Nosepiece | Quintuple, inward facing |
| Optical system | Infinite plan optical system, F=200 mm |
| Condenser | 72 mm extreme long working distance condenser (ELWD), N.A. 0.3 with iris diaphragm |
| Centering telescope eyepiece | 30 mm |
| Stage dimensions | Fixed stage: 240×260 mm, low-position co-axial flexible adjusting handle , Moving range: 135×85 mm Slide plate 118 mm, replaceable Slide plate 76×26 mm, 60 mm replaceable |
| Illumination | 6 V/30W Osram halogen lamp External power, wide voltage (100V to 240 V) Fuse tube 250 V/3.15 A |
| Filter | Blue, green, yellow with 34 mm diameter |
| C-mount | 0.5X |
| Allen screw driver | 2.5 mm diameter |
| Dimension | 650 × 430 × 610 mm |
| Gross weight | 22 kg |
Features
Applications
Inverted Biological Microscope is used for applications in animal & plant tissue culture laboratory, fish laboratory, plant laboratory, poultry laboratory.
Optional Accessories
| Accessories No. | Name |
| 1 | Mechanical stage: 350×208 mm, Moving range: 50×50 mm, low-position co-axial flexible adjusting handle |
| 2 | C-mount 1X, 0.25X (fit 1/3 CCD) |
| 3 | Plan Achromatic 4X/0.13 WD=12.86 mm objective |
| 4 | Plan achromatic positive phase contrast 10X/0.25 WD=9.67 mm objective |
| 5 | Plan achromatic positive phase contrast 40X/0.60 WD=3.76 mm objective |
| 6 | Plan achromatic negative phase contrast 10X/0.25 WD=9.67 mm objective |
| 7 | Plan achromatic negative phase contrast 20X/0.40 WD=7.97 mm objective |
| 8 | Plan achromatic negative phase contrast 40X/0.60 WD=3.76 mm objective |
| 9 | WF10X/22, high eye-point up to 21 mm |
| 10 | WF16X/14 mm |
| 11 | WF10X/20 (pointer), high eye-point up to 21 mm |
| 12 | WF10X/22 (pointer), high eye-point up to 21 mm |
| 13 | Reticule eyepiece: CROSSWF10X/22, high eye-point up to 21 mm |
| 14 | Allen screw driver 2 mm, 3 mm |
Lab Expo inverted biological microscopes have a user-friendly, small, and sleek appearance. They come with a solid and dependable 'T' foundation. They come with phase contrast extended working range targets. They provide clear, high-quality photographs of specimens. They contain trinocular or binocular viewing heads, as well as inverted working stages. They include adjustable center phase contrast ring plates. They provide novel stand constructions and condensers with extremely extended operating distances. Our Inverted Biological Microscopes are excellent for accurate and efficient cell setup and observation.
